Bottom Loading Arm LNG

This bottom loading arm is specifically designed to load Liquefied Natural Gas (LNG) products. It can be used for bottom loading or unloading of road or rail tankers. As with the standard bottom loading arm, due to its long reach, it’s particularly well-suited for applications where it’s difficult to accurately position the tanker connection flange.

The handling of the arm is effortless due to the high-quality design of the swivel joints and precise load arm balancing. The design of the stainless-steel swivel joints is based on the D2000 series, and they’re also equipped with an interchangeable bearing module. The swivel joints are designed to meet the requirements of the OCIMF.

During the entire application time, the operator can monitor leakage via the primary and secondary product seal. Additionally, the ball raceway can be purged with dry gas.
